All right, this is...
This is CS50, Harvard University's Introduction to the Intellectual Enterprises of Computer Science and the Arts of Programming.
My name is David Maylan, and this is Week Zero.
And by the end of today, you'll know not only what these light bulbs here spell, but so much more.
But why don't we start first with the elephant in the room?
That is artificial intelligence, which is seemingly everywhere over the past few years.
And it's been said that it's going to change programming.
And that's absolutely the case.
It's been that way, actually, for the past several years.
It's only going to get to be the case all the more.
But this is an incredibly exciting time.
This is actually a good thing, I do think.
And so far, as now using AI in any number of forms, you can ask the computer to help solve some problem for you.
You can find some bug or mistake in your code.
Better still, increasingly, you can tell the AI what additional features you want to add to your software.
And this is huge, because even in industry for years, humans have been programming in some form for decades,
building products and solutions to problems.
The reality is that you and I, as humans, have long been the bottleneck.
There's only so many hours in the day.
There's only so many people on your team or in your company.
And there's so many more bugs that you want to solve and so many more features that you want to implement.
But at the same time, you still really need to understand the fundamentals.
And indeed, a class like this, CS50, has never been about teaching you how to program.
Like, that's actually one of the side effects of taking a class like this.
But the overarching goal is to teach you how to think, how to take input and produce correct output.
And how to master these and other tools.
And so by the end of the semester, not only will you be acquainted with languages like Scratch,
which we'll touch on today if you've not seen it already.
Languages like C and Python and SQL, HTML, CSS, and JavaScript,
you'll be able to teach yourself new things ultimately
and ultimately be able to tell computers increasingly what it is you want it to do.
But you'll still be in the driver's seat, so to speak.
You'll be the pilot.
You'll be the conductor.
Whatever your preferred metaphor is.
And that's what I think is so empowering still about learning introductory material,
foundational material, because you'll know what you're ultimately talking about
and what you can, in fact, solve.
And we've been through this before.
Like when Calculators came out, it's still valuable.
I daresay all these years later to still know how to do addition and subtraction and whatnot.
And yet I think back on some of my own math classes,
I remember learning so many darn ways in college how to take derivatives and integrals.
And after like the sixth process of that, I sort of realized, OK, I get it.
I get the idea.
Do I really need to know this many ways?
And here, too, with AI and with code, can you increasingly sort of master the ideas
and then lean on a co-pilot assistant to actually help you solve those same problems?
So let's do some of this ourselves here.
In fact, just to give you a teaser of what you'll be able to do yourselves before long,
let me go ahead and open up a little something called Visual Studio Code,
aka VS Code for short.
This is popular largely open source or free software that's used by real world people in industry
to write code.
And it's essentially a text editor, similar to Notepad, if you're familiar with that,
or TextEdit, kind of like Google Docs, but no bold facing and underlining and things
like that that you'd find in word processing programs.
And this is CS50's version thereof.
We're going to introduce you to this all the more next week.
But for now, let's just give you a taste of what you can do with an environment like this.
So I'm going to switch over to this program already running VS Code.
And in this bottom of the screen, you're going to see a so-called terminal window.
Again, more on that next week.
But it's in this terminal window that I can write commands that tells the computer what I want it to do.
For instance, let's suppose, just for the sake of discussion, that I want to make my own chat bot,
not chat GPT or Gemini and Cloud.
Like, let's make our own in some sense.
So I'm going to code up a program called chat.py.
And you might be familiar that I'm using a language here.
.py is it's just called Python.
And if unfamiliar, you're in good company.
You'll learn that too within a few weeks.
And at the top of the file here, I can write my code.
And at the bottom of the file of the window here, I can run my code.
So here's how relatively easy it is nowadays to write even your own chat bot using the AI technologies that we already have.
I'm going to go ahead and type a command like import.
I'm going to go ahead and type the following.
From open AI, import open AI.
We'll learn what this means ultimately.
But what I'm going to do is write my own program on top of an API application programming interface that someone else provides,
a big company called OpenAI.
And they're providing features and functionality that now I can write code against.
I'm going to create a so-called client, which is to say a program of my own that's going to use this OpenAI software.
And then I'm going to go ahead and ask this software for a response.
And I'm going to set that equal to client.responses.create, whatever all that means.
And then inside of these parentheses, I'm going to say the following.
The input I want to give to this underlying API is quote unquote something like, in one sentence, what is CS50?
Much like I would ask ChatGPT itself.
If you're familiar with things like ChatGPT and AI more generally nowadays, you know there is this thing called models,
which are like statistical models that ultimately drive what the AIs can do.
I'm going to go ahead and say model equals quote unquote GPT5, which is the latest and greatest version, at least as of today.
Now, down in my terminal window, I'm going to run a different command, python of chat.py.
And so long as I have made no typographical errors in this program, I should be able to ask OpenAI,
not with ChatGPT.com, but with my own code for the answer to some question.
But I want to know what the answer to that question is.
So I actually want to print out that response by saying print response output text.
In other words, these 10 lines, and it's not even 10 lines because a few of them are blank, I've implemented my own chatbot
that at the moment is hard-coded that is permanently configured to only answer one question for me.
And let's see with the cross of the fingers.
CS50 is Harvard University's introductory computer science course,
the intellectual enterprises of computer science and the art of programming,
weirdly familiar, covering problem-solving algorithms, data structures,
and more using languages like C, Python, and SQL.
OK, interesting.
But let's make the program itself more dynamic.
Suppose you wanted a right code that actually asks the human what their question is,
because very quickly, might we want to learn something more than just this one question?
So up here, I'm going to go and change my code and type something like this.
Type prompt equals input with parentheses.
More on this another time, too.
But what I'm going to ask the user for is to give me an actual prompt.
That is a question that I want this AI to answer.
And down here, what you'll notice, even if you've never programmed before,
is that I can do something somewhat intuitive.
Insofar as line five is now asking the human for input.
Let's just stipulate that this equal sign means store that answer in a variable called prompt,
where variables just like in math, x, y, or z, let's go ahead and store that in prompt.
So the input I want to give to open AI now is that actual prompt.
So it's a placeholder containing whatever keystrokes the human typed in.
If I now run that same command again, Python of chat.py hit Enter, cross my fingers,
I'll see now dynamic prompting.
So what's a question I might want to ask?
Well, let's just say it again.
In one sentence, what is CS50?
Question mark, Enter.
And now the answer comes back as probably, roughly, the same but a little bit different,
a variant thereof.
But maybe we can distill this even more succinctly.
How about let's run it again, Python of chat.py, and let's say in one word,
what is CS50?
And see if the underlying AI obliges.
And after a pause, of course, in a word.
So that's not all that incorrect.
And maybe we can have a little fun with this now.
How about in one word, which is better?
Maybe Harvard or Stanford?
Question mark?
Hope you picked right.
Let's see.
The answer is depends.
OK.
So would not, in fact, oblige.
But notice what I keep doing.
In this code, I keep providing a prompt as the human in one sentence, in one word.
Well, if you want the AI to behave in a certain way,
why don't we just tell the underlying system to behave in that way
so why the human don't have to keep asking in one sentence, in one sentence,
in one sentence, in one word?
So we can actually introduce one other feature
that you'll hear discussed in industry nowadays, which is not only a prompt
from the user, which I'm going to now temporarily rename to user prompt
just to make clear it's coming from the user.
I'm going to also give our what's called a system prompt by setting this equal
to some standardized instructions that I want the AI to respect.
Like limit your answer to one sentence, quote unquote.
And now, in addition to passing in as input, the user prompt,
I'm going to actually tell open AI to use these instructions coming from
this other variable called system prompt.
So in other words, I'm still using the same underlying service,
but I'm handing it now not only what the user typed in, but also this standardized text,
limit your answer to one sentence.
So the human, like me, doesn't have to do that anymore.
Let's now go back to my terminal, run python of chat.py once more,
and this time we'll be prompted.
But now I can just ask, what is CS50 question mark?
And I'll likely get a correct and similar answer to before.
And indeed, it's Harvard University's flagship introductory computer
science course dot dot dot.
So seem spot on too.
But now we can have some fun with this too.
And you might know that these GPTs nowadays have sort of personalities.
You can make them obliged to behave in one way or another.
Why don't we go into our system prompt here and say something silly like,
pretend you're a cat.
And now let's go back to the prompt one final time, run python of chat.py.
Prompt again will be, say, what is CS50?
And with the final flourish of hitting Enter, what do we get back?
CS50 is Harvard University's introductory computer science course teaching
programming, algorithms, data structures, and problem solving.
And it's available free online meow.
So that was enough to coerce this particular behavior.
So this is to say that with programming, you have the ability
in like 10 lines of text, not all of which you might understand yet,
but that's the whole point of a class like this,
to build fairly powerful things, maybe silly things like this.
But in fact, it's using these same primitives that CS50 has its own virtual rubber duck.
And we'll talk more about this in the weeks to come.
But long story short, in the world of programming,
it's kind of a thing to keep a rubber duck literally on your desk
or really any inanimate cute object like this.
Because when you are struggling with some problem, some bug, or mistake
in your code, and you don't have a friend, a teaching assistant, a parent,
or someone else who's more knowledgeable than you about code,
well, you literally are encouraged in programming circles to talk to the rubber duck.
And it's through that process of just verbalizing your confusion
and organizing your thoughts enough to convey it to another person,
or duck in this case, that so often that proverbial light bulb goes off
and you realize, ah, I'm being an idiot, now I hear in my own thoughts
the illogic or the mistake I'm making, and you solve that problem as well.
So CS50 drawing inspiration from this will give to you a virtual duck in computer form.
And in fact, among the other URLs you'll use over the course of the semester is that here,
CS50.ai, which is also built into that previous URL, CS50.dev,
whereby these are the ai's you can use in CS50 to solve problems,
and you are encouraged to do so.
As you'll see in the course of Syllabus, it is not reasonable.
It is not allowed to use AI-based software other than CS50's own,
be it Claude, Gemini, Chatchapiti, or the like.
But it is reasonable and very much encouraged along the way
to turn not only to humans like me, your teaching assistant,
and others in the class, but to CS50's own AI-based software.
And what you'll find is that this virtual duck is designed to behave
as close to a good human tutor as you might expect from an actual human
in the real world, knows about CS50, knows how to lead you to a solution,
ideally without simply spoiling it and providing it outright.
So with that said, that's sort of the end game,
to be able to write code like that and more.
But let's really start back at the beginning
and see how we can't get from zeros and ones that computers speak
all the way back to artificial intelligence.
So computer science is in the name of the course, computer science 50.
But what is that?
Well, it's really just the study of information.
How do you represent it?
How do you process it?
And very much germane to computer science
is what the world calls computational thinking,
which is just the application of ideas from computer science
or CS to problems generally in the real world.
And in fact, that's ultimately, I dare say, what computer science really is.
It's about problem solving.
And even though we use computers, you learn how to program along the way,
these are really just tools and methodologies
that you can leverage to solve problems.
Now, what does that mean?
Well, a problem is perhaps most easily distilled into a simple picture like this.
We've got some input, which is like the problem we want to solve,
and the output, which is the goal we want, the solution there too.
And then somewhere in the middle here is the proverbial black box,
the sort of secret sauce that gets that input from output.
So this then, I would say, in essence, is problem solving, and thus computer science.
But we have to agree, especially if we're going to use devices, Macs, PCs, phones, whatever,
how do we all represent information, the inputs and the outputs, in some standardized way?
Is it with English?
Is it with something else?
Well, you all probably know, even if you're not computer people,
that at the end of the day, computers somehow use 0s and 1s entirely.
That is their entire alphabet.
And in fact, you might be familiar already with certain such systems.
So the unary notation, which means you essentially use single digits,
like fingers on your hand.
For instance, unary, a.k.a. base 1, is something you can do on your own human hand.
So for instance, with one human hand, how high can I count?
All right, so hopefully 1, 2, 3, 4, 5.
And if you want to count to 6 and to 11 and 10 and so forth,
you need to take out another hand or your toes or the like,
because it's fairly limiting.
But if I think a little harder, instead of just using unary,
what if I use a different system instead?
What about something like binary?
Well, how high, if you think a little harder, can you count on one human hand?
So 31 says someone who studied computer science before.
But why is that?
It's kind of hard to imagine, right?
Because 1, 2, 3, 4, 5 seems to be the five possible patterns.
But that's only when you're looking at the totality of fingers that are actually up,
5 in total or 4 in total or 1 or the like.
But what if we take into account the pattern of fingers that are up
and we just standardize what each of those fingers represent?
So maybe we all agree, like a good computer would too,
that maybe no fingers up means the number 0.
And if we want to count to 1, let's go with the obvious.
This is now 1.
But instead of 2 being this, which was my first instinct,
maybe 2 can just be this, a single second finger up like this.
And that means we could now use two fingers up to represent 3, all proposed.
We can use just one middle finger up to offend everyone, but represent 4.
I could maybe use these two fingers with some difficulty to represent 5, 6, 7.
I'm already up to 7 having used only three fingers.
And in fact, if we keep going higher and higher,
I bet I can get as high as 31 for 32 possible combinations.
But the first one was 0, so that's as high as we can count.
So we'll make this connection in just a moment.
But what I started to do there is something called base 2.
Instead of just having fingers up or fingers down,
I'm taking into account the positions of those fingers
and giving meaning to like this finger here, this finger here, this finger here,
and so forth, different weights, if you will.
So the binary system is indeed all computers understand.
And you might be familiar with some terminology here.
Binary digit is not really something anyone really says,
but the shorthand for that is going to be bit.
So if you've heard of bits, and we'll soon see bytes, and then kilobytes,
and megabytes, and gigabytes, and terabytes, and more,
this just refers to a bit, meaning a single binary digit, either a 0 or a 1.
A 0 is perhaps most simply represented by just like turning,
maybe keeping a finger down, or in the world of computers,
which have access to electricity, be it from the wall or maybe a battery.
You know what we could do?
We could just decide universally that when a light bulb is off,
that thing represents a 0.
And when the light bulb is on, that thing's going to represent a 1 instead.
Now, why is this?
Well, electricity is such a simple thing.
It's either flowing or it's not.
And we don't even have to therefore worry about how much of it is flowing.
And if you're vaguely remember a little bit about voltage,
we can sort of be like 0 volts.
Nothing's there available for us, or maybe it's 5 volts or something else
in between.
But what's nice about binary, only how using 0s and 1s
is that it maps really nicely to the real world by throwing a light switch on and off.
You can represent information by just using a little bit of electricity
or the lack thereof.
So what do I mean by this?
Well, suppose we want to start counting using binary, 0s and 1s only.
Well, let's think of them metaphorically as akin to these light bulbs here.
And in fact, let me grab a few of these light bulbs.
And let me propose that if we want to represent the number 0, well,
it stands to reason that here, single light bulb that is off
can be agreed upon as representing 0.
Now, in practice, computers don't have little light bulbs inside,
but they do have little switches inside.
Millions of tiny little things called transistors that if turned on
can allow it to capture a little bit of electricity
and effectively turn on a metaphorical bulb.
Or the switch can go off.
The transistor can go off and therefore let the electricity dissipate.
And you have just now a 0.
Unfortunately, even though I can let some electricity,
here's the battery I mentioned is required,
even though we might have some electricity available to us, I can therefore count to 1.
But how do I go about counting hardware problem?
How do I go about counting higher than 1 with just a light bulb?
Yeah, so I need more of them.
So let me grab another one here.
And now I could put it next to it.
And this 2, I'll claim, is just still the number 1.
But if I want to turn 2 of them on, well, that would mean I could count to 2.
And if I maybe grab another one, now I can count as high as 3.
But wait a minute.
I'm doing something wrong, because with 3 human fingers,
how high was able to count?
So 7 in total, starting at 0.
So I've done something wrong here.
But let me be a little more clever than about the pattern that I'm actually using.
This can still be 1.
But just like my finger went up and only one finger in the second version of this,
this can be what we represent as 2.
Which one do I want to turn on as 3?
Your left or your right?
So you're right, because now this matches what I was doing with my fingers a moment ago.
And I claimed we could represent 3 like this.
If we want to represent 4, that's fine.
We have to turn that off, this off, and this on.
And that's somehow 4.
And let's go all the way up to 7.
Which ones need to be on to represent the number 7?
All right, so all of them here.
Now, if you're not among those who just sort of naturally said all of them,
like what the heck is going on?
How do half the people in this room know what these patterns are supposed to be?
Well, maybe you're remembering what I did with my fingers.
But it turns out you're already pretty familiar with systems like this,
even if you might not have put a name to it.
So in the human world, the real world, most of us
deal every day with the so-called base 10 system.
Otherwise known as decimal, deck implying 10, because in the decimal system,
you have 10 digits available to 0 through 9.
In the binary system, we only had 2, by implying 2, so 0 and 1.
And unary, we had just 1, a single digit there or not.
So in the decimal system, we just have more of a vocabulary to play with.
And yet, you and I have been doing this since grade school.
So this is obviously the number 123.
But why?
It's technically just three symbols, 1, 2, 3.
But most of us, your mind and mind goes, OK, 123.
Pretty obvious.
Pretty natural.
But at some point, you, like me, were probably
taught that this is the 1's place.
And this is the 10's place.
And this is the 100's place, and so forth.
And the reason that this pattern of symbols, 1, 2, 3, is 123,
is that we're all doing some quick mental math and realizing, well, that's 100 times 1,
plus 10 times 2, plus 1 times 3.
Oh, OK, there's how we get 100, plus 20, plus 3 gives us the number we all know
mathematically as 123.
Well, it turns out whether you're using decimal, or binary, or other base
systems that we'll talk about later in the course,
the system is still fundamentally the same.
Let's kind of generalize this away.
Here's a three-digit number in some base system, specifically in decimal.
And I know that only because of the placeholders that I've
got on top of each of these numbers.
But if we do a little bit of math here, 1, 10, 100, 1,000, 10,000, and so forth,
what's the pattern?
Well, technically, this is 10 to the 0, 10 to the 1, 10 to the 2, and so forth.
And we're using 10 because we can use as many as 10 digits
under each of those columns.
But if we take some of those digits away and go from decimal down to binary,
the motivation being it's way easier for a computer
to distinguish electricity being on or off than coming up with, like, 10
unique levels of electricity to distinguish among.
You could do it.
It would be annoying and difficult to build in hardware.
You could do it so much simpler to just say, on and off.
It's a nice, simple world that way.
So let's change the base from 10 to 2.
And what does this get us?
Well, if we now undo the math, that's 2 to the 0 is 1.
2 to the 1 is 2.
2 to the 2 is 4.
So the mental math is now about to be the same,
but the columns represent something a little bit different.
So for instance, if I turn all of these off again,
such that I've got off, off, off, otherwise known as 0, 0, 0,
it's 0 because it's 4 times 0 plus 2 times 0 plus 1 times 0 still gives me 0.
By contrast, if I turn on maybe just this one all the way over on the left,
well, that's 4 times 1 because on represents 1 and off represents 0,
plus 2 times 0 plus 1 times 0, that gives me 4.
And if I turn both of these on such that all three of them are now on,
on, on, on, aka 1, 1, 1, that's 4 times 1 plus 2 times 1 plus 1 times 1,
that then gives me 7.
And we can keep adding more and more bits to this.
In fact, if we go all the way up numerically,
here's how we would represent in binary the number you and I know is 0.
Here's how we would represent 1.
Here's how we would represent 2 and 3 and 4 and 5.
And you can kind of see in your mind's eye now,
because I only have 0s and 1s and no 2s or 3s, not to mention 9s,
I'm essentially going to be carrying a 1 in a moment
if we were to be doing some math.
So to go from 5 to 6, that's why the 1 ends up in the middle column.
To go to 7 here gives us now 1, 1, 1, or on, on, on.
How do I represent 8 using 1s and 0s?
Yeah, so we're going to need to add another digit.
We need to throw hardware at the problem using an additional digit
so that we actually have a column representing 8.
Now, as an aside, and we'll talk about this before long,
if you don't have an additional digit available,
if your computer doesn't have enough memory, so to speak,
you might accidentally count from 0, 1, 2, 3, 4, 5, 6, 7,
and then accidentally end up back at 0.
Because if there's no room to store the fourth bit,
well, all you have is part of the number.
And this is going to create all sorts of problems, then, ultimately, in the real world.
So let me go ahead and put these back and propose that we have a system now
if you agree to sort of count numbers in this way via which we can represent information
in some standard way, and all the device underneath the hood needs
is a bit of electricity to make this work.
It's got to be able to turn things on, a.k.a. use some transistors,
and it's got to be able to turn those things off
so as to represent zeros instead of ones.
But the reality is, like, two bits, three bits, four bits
aren't very useful in the real world, because even with three bits,
you can count to seven, with four, you can count to 15.
This Z aren't very big numbers, so it tends to be more common to actually use
units of measure of eight bits at a time.
A byte is just that.
One byte is eight bits.
So if you've ever used the vernacular of kilobytes, megabytes, gigabytes,
that's just referring to some number of bits,
but eight of them together compose one individual byte.
So here, for instance, is a byte worth of bits, eight of them total.
I've added all the additional placeholders.
And what number does this represent in decimal,
even though you're looking at eight binary digits?
It's a zero, because literally every column is a zero.
Now, this is a bit more of mental math, but unless you know it already,
what if I change all of the zeros to ones?
If I turn all eight light bulbs on, what number is this?
Yeah, so 255.
Now, some of those of you who didn't get that instantly, that's fine.
You could certainly do the math manually.
I daresay some of you have some prior knowledge of how to do this sort of system.
But 255 means that if you start counting at zero and you go all the way up to 255,
OK, that's 256 total possibilities.
Once you include zero in the total number of patterns of zeros and ones.
And this is just going to be one of these common numbers in computer science.
256, why?
Because it's referring to eight of something.
Two to the eight gives you 256.
And so you're going to commonly see certain values like that.
256.
Back in the day, computers could only show 256 colors on the screen.
Certain graphics formats nowadays that you might download can only use as many as 256 colors,
because as we'll see, they're only using, for instance, eight bits.
And therefore, they can only represent so many colors of the rainbow as a result.
So this, then, is how we might go from just zeros and ones, electricity inside of a computer
to storing actual numbers, with which we're familiar.
And honestly, we can go higher than 255.
What do you need to count higher than 255?
A ninth bit, a tenth bit, an eleventh bit, and so forth.
And it turns out common conventions nowadays.
And we'll see this in code two is to use as many as 32 bits at a time.
So that's a good chunk of bits.
And anyone want to ballpark how high you can count if you've got 32 bits available to you?
Oh, fewer people now.
Yeah, in the back.
Yeah, so it's roughly 4 billion.
And it's technically 2 billion if you also want to represent negative numbers.
But we'll revisit that question.
But 2 to the 32nd power is roughly 4 billion.
However, nowadays, it's even more common with the max and PCs you might have on your laps
and even your phones nowadays to 64 bits, which is a big enough number that I'm not
even sure offhand how to pronounce it.
That's a lot of permutations.
That's 2 to the 64 possible permutations.
But that's increasingly commonplace.
And as an aside, just to dovetail things with our discussion of AI,
among the reasons that we're living through over these past few years,
especially this crazy, interesting time of AI,
is because computers have been getting so much faster, exponentially so over time.
They have so much more memory available to them.
There's so much data out there on the internet, in particular,
to train these models that it's an interesting confluence of hardware,
now actually meeting the mathematics and statistics that we'll talk about later
in the class that ultimately make tools like the cat we just built possible.
But of course, computers are not all math.
And in fact, we'll use very little math per se in this class.
And so let's move away pretty quickly from just 0s and 1s
and talk about letters of the alphabet, say in English.
Here is the letter A. Suppose you want to use this letter in an email,
a text message, or any other program.
What is the computer doing underneath the hood?
How can the computer store a capital letter A in English?
If at the end of the day, all the computer has access to is a source of electricity
from the wall or from a battery, and it has a lot of switches
that it can turn on and off and treat the electricity in units of 8 or 32 or 64
or whatever.
How might a computer represent a letter A?
Yeah, we need to give it an identity, so to speak, as an integer.
In other words, at the end of the day, if your entire canvas, so to speak,
consists only of 0s and 1s, that is going to be the answer to every question today.
You only have 0s and 1s as the solution to these problems.
We just need to agree what pattern of 0s and 1s, and therefore what integer,
what number shall be used to represent the letter A.
And hopefully, when we look at that pattern of 0s and 1s in the right context,
we'll indeed see it as an A.
So if we look inside of a computer, so to speak,
in the context of a text messaging program or a word processor or anything like that,
that pattern shall be interpreted, hopefully, as a capital letter A.
But if I open up Mac OSes or Windows or my phone's calculator program,
I would want that same pattern of 0s and 1s to be interpreted instead as a number.
If I open up Photoshop, as we'll soon see,
I want that same pattern of 0s and 1s to be interpreted as a color, presumably,
not to mention videos and sound and so forth, but it's all just 0s and 1s.
And so even though I, when writing that chat program a few minutes ago,
didn't have to worry about telling the computer, oh, this is text.
This is a number.
This is something else, we'll see as we write code ourselves
that you as the programmer will have control over telling the computer
how to treat some pattern of 0s and 1s, telling it this is a number.
This is a color.
This is a letter or something else.
How do we represent the letter A?
Well, it turns out, a bunch of humans in a room years ago
decided this pattern of 0s and 1s shall be known globally as a capital letter English A.
What is that number if you do the quick mental math?
So indeed, 65, because we had a 1 in the 64's place and a 1 in the 1's place.
So 65, that's just sort of it.
It would have been nice if it were just the number 1 or maybe the number 0.
But at least after the capital letter A, they kept things consistent,
such that if you want to represent a letter B, it's going to be 66.
Capital letter C, it's going to be 67.
Why?
Because the humans in this room, a bunch of Americans at the time,
standardized on what's called ASCII, the American Standard Code for Information Interchange.
It doesn't matter what the acronym represents.
But it was just a mapping.
Someone on a piece of paper essentially started writing down letters of the alphabet
and corresponding numbers so that computers subsequently could all
speak that same standard representation.
And here's an excerpt thereof.
In this case, we're seeing seven bits worth.
But eventually, we ended up using eight bits in total to represent letters.
And some of these are fairly cryptic, maybe more on those another time.
But down here, if we highlight just one column, we'll see that indeed.
On this cheat sheet, 65 is capital A. 66 is B. 67 is C, and so forth.
So why don't we do a little exercise here?
What pattern of zeros and ones do I see here?
I've got three bytes, so three sets of eight bits.
And even though there's no placeholders now over the columns, what is this number?
It's 60.
Yeah, so we've got the ones, twos, fours, eights.
16, 32, 64s columns.
So indeed, this is going to be the number 72.
72, this is not what computer scientists spend their day doing.
This is just to reinforce what it is we just looked at, and I'll spoil it.
The rest of these numbers are 72, 73, 33.
And anyone in this room could have done that if you took out a piece of paper,
figured out what the columns are, and just do a bit of quick or mental or written math.
But this is to say, suppose that you just got a text message or an email
that if you had the ability to look underneath the hood of the computer
and see what pattern of zeros and ones did you just receive over the internet,
suppose that pattern of zeros and ones was three bytes of bits,
which, when you do the math, are the numbers 72, 73, 33.
Well, here's the cheat sheet again.
What message did you just get?
Yeah, so it's high.
Why?
Because 72 is h, and 73 is i.
Now, some of you said hi fairly emphatically.
Why?
Well, 33 turns out you wouldn't know this unless you looked it up,
or someone told you is an exclamation point.
So literally, if you were to text someone like right now, if you haven't already,
hi exclamation point in all caps, you would essentially be sending
three bytes of information somehow over the internet to that recipient.
And because their phone similarly understands ASCII,
because it was programmed years ago to do so,
it knows to show you hi exclamation point and not a number, three numbers,
or less, or colors, or something else altogether.
So here we then have hi, three digits in a row here.
What else is worth noting here?
Well, there's some fun trivia embedded even in this cheat sheet.
So here, again, is a, b, c, d, e, f, g, and so forth, 65 on down.
Let me just highlight over here the lowercase letters, 97, 98, 99, and so forth.
If I go back and forth, does anyone notice the consistent pattern
between these two?
Yeah, so the lowercase letters are 32 away from the uppercase letters.
Well, how do we know that?
Well, 97 minus 65 is, yeah, 32.
98 minus 66 is, OK, 32, and that pattern continues.
What does this mean?
Well, computers know how to do this.
Most normal humans don't need this information.
But what it means is, if you are representing in binary with your transistors
on and off, representing some pattern, and this is the pattern,
capital letter a, which is why we have a 1 in the 64th place and a 1 in the 1's place,
how does a computer go about lower casing this same letter?
Yeah.
Perfect.
All the computer has to do is change this one bit in the 32's place to a 1,
because that has the effect mathematically
per our discussion of adding the number 32 to whatever it is.
So it turns out you can force text from uppercase to lowercase
or back by just changing a single bit inside of that pattern of 8 bits in total.
All right.
Why don't we maybe reinforce this with another quick exercise?
We have an opportunity perhaps here for maybe to give you some stress balls right
at the very start of class.
Could we get 8 volunteers to come up on stage, maybe over here and over here
and over here on the left?
Let me go all the way on the right.
Let's see.
OK, the high hand here.
The hand that's highest there.
Yes, we're making eye contact.
How about all the way?
Oh, wait.
Let's see.
Let's go here in the Crimson sweatshirt here and how about in the white shirt here?
Come on up.
Did I count correctly?
Let's see.
Come on down.
The 8th of view.
I didn't count right, did I?
1, 2, 3, 4, 5, 6.
It's ironic that I'm not counting correctly.
It's here.
How about on the left in gray?
OK.
Oh, and OK.
In black here.
Come on down.
All right.
Hopefully this is 8.
1, 2, 3, 4, 5, 6, 7, 7.
OK, 8.
There we go.
All right.
So let's go ahead and do the following exercise.
I've got some sheets of paper pre-printed here.
If each of you indeed want to do exactly what you're doing in lineup from left to right,
each of you is going to represent a place holder, essentially.
So we have over here the ones place all the way over here.
And then we have the choose place and the fourth place and the 8th.
16, 32, 64, 128.
And we come bearing a microphone.
If each of you want to say a quick hello, your name, maybe your dorm or house,
and something besides computer science that you're studying or want to.
Hi.
I'm out.
That's loud.
OK.
I'm Allison.
I'm a freshman in Matthews.
And I like climbing.
And I'm thinking of CS and Econ.
Number two.
Hi.
I'm Lily.
I'm in Herlbut this year.
And I'm thinking of doing CS in government.
Nice to meet you.
Hi.
I'm Sean.
I'm in Canada Hall.
And I'm thinking of doing astrophysics and CS.
Welcome.
Hi.
I'm Jordan.
I'm doing applied math with a specialization in CS and Econ.
And I'm in Widdlesworth.
And I like going to the gym.
OK.
Nice.
16.
Hi.
I'm Shiv.
I'm studying Mackey.
And I'm in Canada, EG.
Nice.
Hi.
I'm Sophia.
I'm in Thayer.
And I'm thinking of doing electrical engineering.
Welcome.
Hi.
My name is Marie.
And I'm in Canada, AB.
And I really like CS physics and astrophysics.
Hi.
I'm Alyssa.
I'm in Holworthy.
I'm also thinking of studying math or physics.
And I also like to climb.
Nice.
Welcome to you all.
So on the backs of their sheets of paper,
they have a little cheat sheet that's describing what they should
do in each of three rounds.
We're going to spell out together a three letter word.
You all, as the audience, have a cheat sheet above you
that represents numbers to letters.
These folks don't necessarily know what they're spelling.
They only know what they individually are spelling.
So if your sheet of paper tells you to represent a zero in a given round,
just kind of stand there awkwardly, no hands up.
But if you're told on your sheet of paper to represent a one,
just raise a single hand to make obvious to the audience
that you're representing a one and not a zero.
And the goal here is to figure out what we are spelling using this system
called ASCII.
All right.
Round one, execute.
What number is this here?
I'm hearing ssss.
You can just shout it out.
What number?
66.
66 or B.
So you're spelling B. All right.
Hands down.
Round two.
More math.
Feel free to shout it out.
Oh, I heard it.
Yes, 79, which is O.
OK, so we have B, O.
Hands down.
Third and final round.
Execute.
Number?
Yes, 87, which is the letter?
W, which spells?
Bow.
If you want to take your bow now.
Ah, OK.
Here we go.
You guys can keep those.
Thank you.
Thank you.
OK.
Thank you.
All right.
You guys can head back.
Our volunteers here very nicely done.
We indeed spelled out bow.
And that's just because we all standardized on representing information
in exactly the same way, which is why when you type B-O-W on your phone
or your computer, the recipient sees the exact same thing.
But what's noteworthy in this discussion is that you can't spell a huge number of words.
Like, yeah, English.
OK, we've got that covered.
But odds are you're noticing, depending on your own background,
what human languages you read or speak yourself,
that a whole bunch of symbols might be missing from your keyboard.
For instance, we have accented characters here in a lot of Asian languages.
There's so many more glyphs than we could have even fit in that cheat sheet of numbers and letters.
And so ASCII is not the only system that the world uses.
It was one of the earliest.
But we've moved on in modern times to a superset of ASCII that's generally known as Unicode.
And Unicode uses so many more bits than ASCII that we even have room for all of these little things
that we seem to extend constantly nowadays.
These are obviously images that you might send with your phone or your computer.
But they're technically characters.
They're technically just patterns of zeros and ones that have similarly been standardized around the world
to look a certain way.
But this is an emoji keyboard in the sense that you're sending characters.
You're not sending images per se.
The characters are displayed as images, obviously.
But really, these are just like characters in a different font.
And that font happens to be very colorful and graphical as well.
Unicode, instead of using just seven or eight bits, which if you do the quick mental math,
if ASCII only used seven or let's say eight bits, how many possible characters can you represent in ASCII alone?
256, because if we do that quick mental math, two to the eighth, 256 possibilities, like that's it.
That's enough for English, because you can cram all the uppercase letters, the lowercase letters,
the numbers, and a whole bunch of punctuation as well.
But it's not enough for certain other punctuation symbols, not to mention many other human languages.
And so the Unicode consortium, its charge in life,
has been to come up with a digital representation of all human language,
past, present, and hopefully future, by using not just seven or eight bits,
but maybe 16 bits per character, 24 bits, or heck, even 32 bits per character.
And per before, if you've got as many as 32 bits available to you,
you can represent what, like, four billion characters in total.
And that's just one of the reasons why these emoji have kind of exploded in popularity and availability.
There's just so many darn patterns, like, what else are we going to do with all of these zeros and ones?
But more importantly, emoji have been designed to really represent people and places and things and emotions
in a way that transcends human language.
But even then, they're somewhat open to interpretation.
In fact, here's a pattern of, I think, 32 zeros and ones.
Guessing no one's going to do the quick mental math here.
But this represents what decimal number, if we do, in fact, do out the mouth,
with that being the ones place all the way over to the left?
Well, that's the number, 4 billion, 36 million, 991,106.
Who knows what that is?
It's not A, and it's nothing near A, uppercase or lowercase.
But it is among the most popular emoji that you might send typically on your phone, laptop, or other device,
namely this thing here, face with tears of joy, which odds are you've sent or received recently.
But interestingly, even though many of you might have iPhones and see and send the same image,
you'll notice that if you see a friend who's got Android or some other device,
maybe you're using Meta's Messenger program or Telegram or some other messaging service,
sometimes these emoji look a little bit different.
Why?
Because what a Unicode has done is they decided there shall exist an emoji known as, excuse me, face with tears of joy.
Then Apple and Google and Microsoft and others, they're sort of free to interpret that as they see fit.
So what you see on the screen here is a recent version from iOS, Apple's operating system.
Google's version of the same looks a little something like this.
And on Telegram, if you have animations enabled,
the same idea faced with tears of joy is actually animated.
But it's the same pattern of zeros and ones in each case.
But again, they each essentially have different graphical fonts
to present to you what each of those images actually is.
All right.
So those are each, excuse me, images.
So those are each images.
How is the computer representing them, though?
At the end of the day, we've represented numbers.
We've represented letters.
But how about these things here, colors?
So how do we represent red or green or blue?
Not to mention every other color in between.
At the end of the day, we only have one canvas at our disposal.
Yeah.
So integers is the exact same answer as before.
We just need to agree on what number do we use for red?
What do we use for green?
What do we use for blue?
And we can come up with some standardized pattern for this.
In fact, one of the most common techniques for doing this
and one of the most common ways to do this in the real world
is to use a combination of three colors together.
Some amount of red, some amount of green, and some amount of blue.
And mix them together to get most any color of the rainbow that you might want.
This is sort of a picture of something I grew up with back in the day,
where in middle school, when we'd watch movies or some kind of show in class,
the projector screen would be over here.
This is an old school projector with three different lenses,
one of which projects some amount of green, some amount of red, some amount of blue.
And so long as the lenses are correctly oriented to all point at the same circle,
or rectangular region on the screen, you would see any number of colors
coming to life in the old school video.
And I still remember all these years later,
we would kind of sit and lean up against it because it was super warm
and you could feel an easy way to fall asleep back in grade school.
But we use the same fundamental color system nowadays as well,
including in modern programs like Photoshop.
So let's abstract that away, focus on just three colors, some amount of red,
green, and blue.
And let's propose for the sake of discussion
that we want to mix together like a medium amount of red,
a medium amount of green, and just a little bit of blue.
For instance, let's propose that we'll use 72 amount of red,
72 amount, 73 amount of green, or 33 amount of blue, RGB.
Now, why these numbers?
Well, in the context of ASCII or Unicode, which is just a superset thereof,
what is this spell?
High.
But again, if you were instead to open a file containing these three numbers,
or really these three bytes of bits in Photoshop,
we would hope that they're going to be interpreted not as letters on the screen,
but as the color of a dot on the screen instead.
So it turns out that typically when you have three of these numbers together,
each of them is using a single byte, so eight bits.
So you can have 0 red or 255 red, 0 green or 255 green or 0 to 255 of blue.
So 0 is none, 255 is the max.
If you mix these together, imagine just like that projector consolidating
these three colors into one central point.
Anyone want to guess what you're going to get if you mix some red, some green,
some blue in those amounts and way back?
Yeah, you're going to get a dark shade of yellow.
I've brightened it up a little bit for the projector here,
but you're going to get roughly this shade of yellow.
And we could play with these numbers all day long and get similar results
if we want to represent different colors as well.
And indeed, whether it's Photoshop or some other program,
you can actually combine these amounts in all sorts of ratios
to get different colors.
So if you had 0, 0, 0, so no red, no green, no blue,
take a guess as to what color that's going to be in the computer.
So it's going to be black, like the absence of all three of those colors.
But if you mix the maximal amount of each of those, 255 red and green and blue,
that's going to give you white.
Now, if any of you have made web pages before or used programs like Photoshop,
you might have seen numbers like 0, 0 or FF, long story short.
That's just another base system for representing numbers between 0 and 255
as well.
But we'll come back to that mid-semester when we make some of our own filters
in sort of an Instagram-like way, manipulating images of our own.
So where are these colors coming from?
Or where can we actually see them?
Well, here's just a picture of that same emoji, face with tears of joy.
If I kind of zoom in on that and maybe zoom in again,
you can start to see if you blow it up enough or if you put your eyes close
enough to the device sometimes, you can actually see individual dots or squares.
These are generally known as pixels.
And they're just the individual dots that collectively compose an image,
which is to say that if each of these dots, which is part of the image,
is going to be a distinct color, like this one's yellow, this one's brown,
and then there's a bunch in between, well, you're using some number of bits
to represent each of those pixels' colors.
So if you imagine using the RGB system, that's 8 plus 8 plus 8 bits.
So that's 24 bits or 3 bytes just to keep track of the color of each and every one
of these dots.
So now if you think about having downloaded a JIF at some point, a Ping, PNG file,
a JPEG, or any other file format, it's usually measured in what file size?
Like megabytes, typically.
That means millions of bytes.
Why?
Because if it's a pretty big photograph or pretty big image,
each of those dots takes up at least three bytes, it would seem.
And if you do out the math, if you've got thousands of dots,
each of which uses three bytes, you're going to quickly get to megabytes,
if not even larger, for things like, say, videos.
But again, it's just patterns of zeros and ones.
And so long as the programmer knows what they're doing and tells the computer
how to interpret those zeros and ones, and equivalently, so long as the software
knows, look at these zeros and ones and interpret them as numbers, or letters,
or colors, we should see what we intended to represent.
All right, so that's colors and images.
What about how many of you kind of played with these little flip books
as a kid, where they've got like 100 different little pictures,
and you flip through them really quickly, and you see what looks like animation
in book form?
Well, this is essentially a video.
So therefore, what is a video?
Or how can you think of what a video is?
It's just a whole bunch of images flying across the screen, either on paper
or digitally nowadays on your phone or your laptop.
And that's kind of nice, because we're sort of composing more interesting media now
based on these lower-level building blocks.
And this is going to be thematic.
We literally started with zeros and ones.
We worked our way up to letters.
We then worked our way up to sort of images and colors and those images.
Now we're up at this level of hierarchy in terms of video, because what's a video?
It's like 30 images per second flying across the screen,
or maybe slightly fewer than that, that collectively tricks our mind
into thinking we are seeing motion pictures.
And that's the old school term for movies, but it literally is what it was.
Motion pictures was this film was showing you 30 pictures per second,
and it looks like motion, even though you're just looking at images,
much like this flip book, very quickly, one after the other.
What about music?
Well, how could you go about representing musical notes?
If, again, your only ingredients are zeros and ones?
Even if you're not a musician, how do you represent music like that on the screen here?
Yeah.
OK, so the frequency, like the tone that you're actually hearing from the device,
what else might weigh in besides the frequency of the note?
Yeah.
So the speed of the note, maybe the duration.
Like if you think about a physical piano,
like how long you're holding the key down for or not, what else?
So the amplitude, maybe how loud?
Like how hard did you hit the keyboard to generate that sound?
So let me propose, at the risk of simplifying,
we could represent each of these notes using three numbers, maybe zero to 255,
or some other range that represents the frequency or the pitch of the note,
the duration, and the loudness.
And so long as the person receiving a file containing all of those zeros and ones
knows how to interpret them three at a time,
I bet you could share a musical file with someone else
that they could hear in exactly the same way that you yourself intended.
Let me pause here to see if there's any questions now,
because we've already built our way up from zeros and ones now to video and sound.
Yeah, in front.
How does the computer know the difference between what the letter like 65 would be
and then what the number 65 would be?
So how does the computer distinguish between the letter 65 and the number 65?
It's context dependent.
So put simply, and we'll see this as early as next week,
the programmer tells the computer how to display the information,
either as a number or a letter, or equivalently, once programmed,
the software knows that when it opens a .gif file or .jpeg or something else
to interpret those zeros and ones as colors,
instead of as .docx for a Microsoft Word file or the like.
Other questions on any of these representations?
Yeah, in front.
Can we go over like the base 10, base 2 thing, like really briefly?
Sure, so can we go base 10 and base 2?
So base 10 is like literally the numbers you and I use every day.
It's base 10 in the sense that you have 10 digits at your disposal, 0 through 9.
And any numbers you want to represent in the real world
must be composed using 0 through 9.
The binary system, or base 2, is fundamentally the same.
It's just the computer doesn't have access to 2 through 9.
It only has access to 0 and 1.
But much like the light bulbs I was displaying here,
you can simply ascribe different weights to each of the digits
so that instead of it being as much as the ones place, the tens place,
and the hundreds place, if we more modestly say the ones place,
the twos place, the fours place, we can use the same system.
In binary, you might need to use more digits to account as high.
Because in 255, you can just write 255.
That's three digits in decimal.
But in binary, we've seen you need to use eight such digits,
which is more, but it's still much better than unary,
which would have had 255 light bulbs on instead.
Is binary and base 2 the same thing?
Is binary and base 2 the same thing?
Yes.
Just like base 10 and decimal are the same thing as well,
and unary and base 1 are the same thing as well.
All right.
So let me just stipulate that even though we sort of took this tour quickly,
at the end of the day, computers only have 0s and 1s at their disposal.
So again, the answer to any question is to how can we represent x is going
to somehow involve permuting those 0s and 1s into patterns,
or equivalently into the numbers that they represent.
But if we now have a way to represent all inputs in the world,
be it letters, numbers, images, videos, anything else,
and get output from some problem solving process,
like how do we actually solve problems?
Well, the secret sauce in the middle here
is another term that you've probably heard in the real world
nowadays, which is that of algorithm.
Step-by-step instructions for solving some problem.
So this ultimately is what computer science really
is about, too, is not just representing information,
but somehow processing it, doing something interesting with it
to actually solve the problem that you've been provided as input
so you can output the correct answer.
Now, there's all sorts of algorithms implemented in our phones,
and in our Macs, and PCs, and that's all software is.
It's an implementation in code, be it C++, or Java, or anything else.
Other languages exist, too, in code that the computer understands,
but it's still just step-by-step instructions.
And among the things we'll learn in CS50 is
how to express yourself in different ways to solve problems,
not only in different languages, but using different methodologies
as well.
Because as we'll see, among the reasons
we introduced these several languages is you
don't just learn more and more languages that allow you to solve
the same problems.
Different languages will allow you to solve different problems
and even save you time by being better tools for the job.
So here, for instance, on an iPhone is maybe a bunch of contacts,
which is presumably familiar, where we might have a whole bunch of friends
and family and whatnot alphabetized by first name or last name.
And suppose we want to find one such person, like John Harvard, whose
number here might be plus one, 949-468-2750.
Feel free to call or text him sometime.
This is the goal of this problem.
If we have our contacts app and I start typing in John's name by first name
or last name, the autocomplete nowadays kicks in,
it somehow filters the list down from my 10 friends or 100 friends
or 1,000 friends into just the single directory entry that matches.
So here, too, back in the days of R, G, and B projectors,
we had phone books like this here, too.
I'm pleased to say, thanks to our friend Alexis,
this is the largest phone book that we've used for this demonstration.
This is an old school phone book that's essentially the same thing
as our contacts app or address book nowadays,
whereby I've got a whole bunch of names and numbers alphabetically
sorted by first name or last name, whatever,
and corresponding to each of those as a number.
So back in the day, and frankly, even nowadays in your phones,
how do you go about finding someone in a phone book or your contacts app?
Well, you could very naively just start at the beginning and look down
and just turn one page at a time, looking for John Harvard in this case.
Now, so long as I'm paying attention, this step-by-step process
will get me to John Harvard.
Like, this is a correct algorithm, even though you
might kind of object to how I'm doing this.
Why?
What's bad about this algorithm?
It's just slow.
I mean, this is crazy slow.
If there's like 1,000 pages in this phone book, which looks like there are,
like this could take me as many as 1,000 pages,
or maybe he's roughly in the middle, so like 500 pages, like that's crazy.
That's really rather slow, especially if I'm going to do this again and again.
Well, what if I do it a little smarter?
Grade school, I sort of learned how to count two at a time, so 2, 4, 6, 8, 10,
12, 14, 16, 18.
Again, if I'm paying attention, I'll get there twice as fast,
because I'm counting two at a time, but is that algorithm step-by-step correct?
And I'm seeing no, but why?
I might skip over John Harvard.
So just by bad luck and kind of with 50-50 probability,
he's going to be sandwiched between two of the pages.
Now, I don't have to abort this algorithm altogether.
I could just, as soon as I get past the J section,
if we're doing it by first name, I could just double back one page
and just make sure that I haven't missed him.
So it's recoverable, and this algorithm, therefore,
is sort of twice as fast, plus one extra step, maybe, to double back.
But that's arguably otherwise a bug or a mistake in the algorithm
if I don't fix it intelligently.
But what do we do back in the day?
And what does your iPhone or Android phone do?
What they typically do is they go roughly to the middle,
look physically or virtually down.
They see, oh, I'm in the M section.
And so which side is John Harvard to?
To the left or to the right?
So he's to the left.
So I could literally now turn.
Jesus Christ.
We talked about this before class.
And this might be more.
Oh, my god.
There we go.
We can tear the problem in half.
Thank you.
It's been a while.
We can tear the problem in half.
We know that John Harvard is to the left,
so I can throw half of the problem away, dramatically,
such that I've now gone from a 1,000 page problem to 500 pages instead.
What now can I do?
I can go roughly to the middle here, and maybe I'm in the E section.
So I went a little too far back to the left, but I kept it simple,
and I just divided so that I can conquer this problem, if you will.
And if I'm in the E section now, it's John Harvard to the left or to the right.
To the right.
So I can get him.
Jesus Christ.
Tear the problem in half.
And now, thank you.
So now, John Harvard, again, is going to be in this half.
I can throw this half away.
So now I've gone from 1,000 to 500 to 250,
and I can repeat, repeat, repeat down to 125, half of that,
half of that, half of that, until I'm left with, finally, just a single page.
And John Harvard is hopefully now on this page, such that I can call him,
or not at all, at which point this is all sort of for not.
But what's powerful about each of those algorithms
is that it's a sort of good, better, and best.
Like, they all get the job done, conditional on the second one,
having that little fix, just to make sure I don't miss John Harvard
between two pages.
But they're fundamentally different in their efficiency
and the quality of their design.
And this is really representative of one
of the emphases of a class like this.
It's not just about writing correct code or getting the job done,
but doing it well and doing it quickly, using the least amount of CPU
or computing resources, using the minimal amount of RAM,
using the fewest number of people, using the least amount of money.
Whatever your constrained resource is, solving a problem better.
So that first algorithm, step-by-step instructions,
was all about doing something like this, whereby the first algorithm,
if we plot things on a grid like this, we
have on the x-axis a representation of the size of the problem.
So this would mean small problem, like zero pages.
This would mean big problem, like 1,000 pages.
And on the y or vertical axis, we have some measurement of time.
So this is the number of seconds, so the number of page turns,
whatever your metric actually is.
So this would be not much time at all, so fast.
This would be a lot of time, so slow.
So what's the relationship if we just roughly draw these three algorithms?
Well, the first one is technically a straight line.
And we'll describe that as n.
The slope is n, because if you think of n
as a number for the number of pages, well, there's a one-to-one relationship.
And the first algorithm, as to how many times
I have to turn the page based on how many pages there actually is.
And you can think about this in the extreme.
If I was looking for someone whose name started with z,
I might have to go through like 1,000 darn pages
to get to that person whose name started with z.
Unless, again, I do something hackish and just kind of cheat and go to the end.
If we execute these algorithms again and again in the same way,
that's going to be pretty slow.
But the second algorithm was pretty much twice as fast,
plus that one extra step potentially.
But it's still a straight line, because if there's 1,000 pages
and I'm dividing the problem and doing two pages at a time,
well, that's like n divided by two steps, plus one, give or take.
But it's still a straight line, but it's still better.
Notice if this is the size of the problem, 1,000 pages for instance,
we'll notice that the first algorithm took literally twice as much time
as the second algorithm.
So we're doing better already.
But the third algorithm, fundamentally, is going to look something like this.
And if you remember your logarithm, so to speak, sort
of the opposite of an exponential, this curve is so much lower and flatter
if you will than either of these two.
Mathematically, more on this another time, the slope
is going to be like log base 2 of n, or just logarithmic in nature.
But what it means is that it's growing very, very, very slowly.
It's still going up.
It's never going to flat line and go perfectly horizontal,
but it goes up very slowly.
Why?
Well, if you think about two towns nearby,
like Cambridge on this side of the river and the town of Alston on the other,
suppose that they still have phone books like this one
and they merge their phone books for whatever reason.
So overnight, we go from 1,000 page phone book to a 2,000 page phone book.
The first algorithm is going to take literally twice as long as will
the second one, because we're only going through it one or two pages at a time.
But if the phone book size doubles from this year, for instance, to next year,
you can kind of in your mind's eye think about the green line.
It's not going to go up that much higher.
Why?
Well, practically speaking, even if the phone book becomes 2,000 pages long,
well, how many more times do you have to tear or divide that problem in half?
Just one, because you're taking a 1,000 page byte out of it or 500, then a 250.
You're taking much bigger bytes out of it than just one or two at a time.
And so what computer science and what algorithms and about good design is
about is figuring out what is the logic via which you can solve problems,
not only correctly, but efficiently as well.
And that then gives us these things called algorithms.
And when it comes time to code, which we're about to do too,
code is just an implementation and a language
the computer understands of an algorithm.
Now, this assumes that we've come up with some digital way that is to say,
0 and 1 based way to represent names and numbers.
But honestly, we already did that.
We came up with ASCII and then Unicode to represent the names.
Representing numbers is even easier than that.
That's really where we started.
So code is just about taking as input some standardized representation
of names and numbers and spitting out answers.
And that's truly what iOS and Android are doing.
When you start doing autocomplete, they could
be searching from the top to the bottom, which
is fine if you've only got a few friends and family in the phone.
But if you've got 1,000 or if you've got 10,000 or if it's not a phone book
anymore, it's some database with lots and lots of data.
Well, it stands to reason that it'd be nice maybe if the computer kept
it all alphabetized, just like that book, and jumped to the middle,
then the middle of the middle, then the middle of the middle of the middle,
and so forth, why?
Because the speed is going to be much, much faster, logarithmic in nature
and not linear, so to speak, in nature.
But we'll revisit those topics as well.
But for now, before we get into actual code,
let's talk for a moment about pseudocode.
So pseudocode is not one formal thing.
Every human will come up with their own way of representing pseudocode.
It's an English-like or human-like formulation of step-by-step instructions
just using terse correct English or whatever human language.
So for instance, if I want to translate what I did somewhat intuitively
with that phone book by just dividing in half, dividing in half,
into step-by-step instructions, I could hand you, or now it is like a robot,
or something like that.
Well, step one was essentially to pick up the phone book, which I did.
Step two was I opened to the middle of the phone book
in the third and final algorithm.
Step three was look at the page as I did.
Step four got a little more interesting.
Even though I didn't verbalize this, presumably,
I was asking myself a question.
If the person I'm looking for, John Harvard, is on the page,
then I would have called him right then.
But if he weren't on the page, if he instead were earlier in the book,
as did happen, well, then I'm going to go to the left, so to speak.
But more methodically, I'm going to open to the middle of the left half
of the book, then I'm going to go back to line three.
That's interesting.
We'll come back to that in a moment.
But else, if the person is later in the book,
I'm going to open to the middle of the right half of the book,
and then go back to line three.
Now let's pause here.
Why do I keep going back to line three?
This would seem to get me doing the same thing forever endlessly,
but not quite.
Why?
Because as soon as you hit the one, the condition on line four.
Yeah.
So because I am dividing the problem in half, for instance,
on line six or line nine implicitly, just based on how I've written this,
the problem's getting smaller and smaller and smaller.
So it's fine if I keep doing the same logic again and again,
because if the problem's getting smaller,
eventually it's going to bottom out, and I'm going to have just one person
on that page that I want to call, and so the algorithm's done.
But there is a perverse corner case, if you will,
and this is where it's ever more important to be precise when writing code
and anticipate what could go wrong.
I should probably ask one more question in this code, not just these three.
What might that question be?
Yeah?
Like, if John Harvard is in the book?
Yeah, so if John Harvard is not in the book, there's this corner case
where what if I'm just wasting my time entirely and I get to the end
of the phone book and John Harvard's not there, what should the computer do?
Well, as an aside, if you've ever been using your Mac or PC or phone
and the thing just freezes or like the stupid little beach ball starts spinning
or something like that and you're like, what is going on,
some human at Google or Microsoft or Apple or the like made a mistake.
They forgot, for instance, that fourth uncommon but possible situation
wherein if they don't tell the computer how to handle it,
the computer is effectively going to freak out and do something undefined,
like just hang or reboot or do something else.
So we do want to add this.
Elts quit altogether.
So you have well-defined behavior.
And truly think that the next time your computer or phone spontaneously
reboots or dies or does something wrong, it's probably not your fault,
per se.
It's some other human elsewhere did not write correct code.
They didn't anticipate cases like these.
But now let's use some terminology here.
There's some salient ideas that we're going to see in Scratch and C
and Python and these other languages I alluded to earlier.
Everything I've just highlighted here, henceforth,
we're going to think of as functions.
Functions are verbs or actions that really get
some small piece of work done for you.
Functions are verbs or actions.
Here, though, highlighted is the beginning of what we'll call conditionals.
Conditional is like a fork in the road.
Do I go this way?
Do I go this way?
Or some other way altogether?
How do you decide what road to go down?
We're going to call these questions you ask yourself, Boolean expressions,
named after a mathematician, Boole.
And a Boolean expression is just a question that has a yes or no answer,
or a true or false answer, or a one or zero answer.
Just it's a binary state, yes or no, typically.
Otherwise, we have this, go back to, go back to,
which is what we're generally going to call a loop, which somehow induces
cyclical behavior again and again.
And those functions and those conditionals, Boolean expressions,
and loops, and a few other concepts are pretty much what will underlie all
of the code that we write, whether it is in Scratch, C, or something else
altogether.
But we need to get to that point.
And in fact, let's go and infer what this program here does.
The end of the day, computers only understand 0s and 1s,
so I claim here is a program of 0s and 1s.
What does it do?
Anyone want to guess?
I mean, we could spend all day converting all of these 0s and 1s
to numbers, but they're not going to be numbers if it's code.
What do you think?
That's amazing.
It does, in fact, print, hello world.
All right, so no one, except maybe you and me and a few others in the room,
should know, and that was probably guess admittedly, or advancing on the slide.
But why is that?
Well, it turns out that not only do computers
standardize information, data, like numbers, and letters, and colors,
and other things, they also standardize instructions.
And so if you've heard of companies like Intel, or AMD, or NVIDIA, or others,
among the things they do is they decide as a company
what pattern of 0s and 1s shall represent what functionality.
And it's very low level functionality.
Those companies and others decide that some pattern of 0s and 1s
means add two numbers together, or subtract, or multiply.
Another pattern might mean load information from the computer's
hard drive into memory.
Another might mean store it somewhere else.
Another might mean print something out to the screen.
So nested somewhere in here, and admittedly,
I have no idea which pattern off hand, because it's not interesting enough
to go figure it out at this level, says print.
And somewhere in there, like this gentleman proposed,
I bet we could find the representation of H, which was 72, and E, and L,
and L, and O, and everything that composes Hello World.
Because as it turns out, in programming circles,
the very first program that students typically write is that of Hello World.
Now this one here is written in a much more intelligible way.
Even if you're not a programmer, odds are, if I asked you, what does this program do,
you would have said, oh, Hello World, even though there's a lot of clutter here.
No idea what this is until next week.
Int main void, that looks cryptic.
There's these weird curly braces, which we rarely use in the real world.
But at least I understand a few words like hello in world.
And this is kind of familiar, print F, but it's not print,
but it's probably the same thing.
So here too is an example of this hierarchy.
Back in the day, in the earliest days of computers, humans were writing code
by representing zeros and ones.
If you've ever heard your parents talk about punch cards or the like,
they're effectively representing patterns that tell the computer what to do
or what to represent, like literally holes in paper.
Well, pretty quickly early on, this got really tedious,
only writing code at such a low level.
So someone decided, you know what, I'm going to put in the effort.
I'm going to figure out what patterns of zeros and ones I can put together
so as to be able to convert something more user friendly to those zeros and ones.
And as a teaser for next week, that person
invented the first compiler, a compiler is just
a program that translates one language to another.
And more modernly, this is a language called C,
which we'll spend a few weeks on together because it's so fundamental
to how the computer works.
Even this is going to get tedious by like week six of the class.
And this is going to get stupid.
This is going to get annoying.
This is going to get cryptic.
We're just going to write print hello on the screen
in order to use a different language called Python.
Why?
Because someone wrote in C a program that can convert Python.
This is a white lie.
To C, which can then be converted to zeros and ones and so forth.
So in computing, there's this principle of abstraction
where we start with the basics.
And thank god we can all trust that someone else solved
these really hard problems way long ago.
Then they wrote programs to make it easier.
We write programs to make it easier.
You can now code like I did with the chat bot to make things even easier.
Why?
Because OpenAI and other companies have abstracted away
a lot of the lower level implementation details.
And that's where I think this stuff gets really exciting.
We can stand on the shoulders of others
as long as we know how to use and assemble these kinds of building blocks.
And speaking of building blocks, let's start here.
Now odds are some of you might have started here in grade school playing
with Scratch.
And it's great for after school programs learning how to program.
And you probably used this language to make games and graphics
and just maybe playful art or the like.
But in Scratch, which is a graphical programming language designed
about 20 years ago from our friends down the road at MIT's Media Lab,
it represents pretty much everything we're
going to be doing fundamentally over the next several weeks
in more modern languages, like C and Python, more textual languages,
if you will.
I bet I could ask the group here, what does this program do when you click
a green flag?
Well, it says hello world on the screen.
Because with Scratch, you have the ability
to express yourself with functions and loops and conditionals and all
of this, but by using drag and drop puzzle pieces.
So what we're about to do is this.
We're going to go on my screen to scratch.mit.edu.
It's a browser-based programming environment.
We're only going to spend one week, or really a few days, in CS50 on this language.
But the overarching goal is to, one, make sure everyone's comfortable
applying some of these building blocks and actually developing
something that's interesting and visual and audio as well,
but to also give us some visuals that we can rely on and fall back on when
all of those curly braces and parentheses and sort of stupid syntax
comes back that's necessary in many languages but can very quickly
become a distraction early on from the interesting and useful ideas.
So what we're about to see is this in a browser.
This is the Scratch programming environment,
and there's a few different parts of this world.
This is the blocks palette, so to speak.
That is to say, there's a bunch of puzzle pieces or building blocks
that represent functions and conditionals and loops and other such constructs.
There's going to be the programming area here where you can actually write your code
by dragging and dropping these puzzle pieces.
There's a whole world of sprites here.
By default, Scratch is a cat by design, but you
can make Scratch look like a dog, a bird, a garbage can, or anything else,
as we'll soon see.
And then this is the world in which Scratch itself lives.
So Scratch can go up, down, left, right, and generally be animated
within that world.
For the curious, kind of like high school geometry class,
there's sort of this xy plane here, so 0, 0 would be in the middle.
0, 180 is here.
0, negative 180 is here.
Negative 240, 0 is here.
And positive 240, 0 is here.
Generally, you don't need to worry about the numbers,
but they exist so that when you say up or down,
you can actually tell the program go up 1 pixel or 10 pixels or 100 pixels
so that you have some definition of what this world actually is.
All right, so let's actually put this to the test.
Let me go ahead here and flip over to, in just a moment,
the actual Scratch website, whereby I'm going to have on my screen
just a moment, that same user interface, once I've logged in,
that via which I can actually write some code of my own.
Let me go ahead and zoom in on the screen a little bit here.
And let's make the simplest of these programs first.
Maybe a program that simply says hello world.
Now, at a glance, it's kind of overwhelming how many puzzle pieces
there are.
And honestly, even over 20 years, I've never used them all.
And MIT occasionally adds to it.
But the point is that they're color coded to resemble the type of functionality
that they offer.
And also, it's meant to be the sort of thing
where you can just scroll through and get a visual sense of what you could do
and then figure out how you might assemble these puzzle pieces together.
So I'm going to go under this yellow or orange-ish category here to begin with.
So there exists in the world of Scratch not quite the same jargon
that I'm using now, functions, and conditionals, and loops.
That's more of the programmer's way.
This is more of the child-friendly way, but it's really the same idea.
Under events, you have puzzle pieces that represent
things that can happen while the world is running.
So for instance, the first one here is sort of the canonical when the green flag is clicked.
Why is that relevant?
Well, in the two-dimensional world that Scratch lives in,
there's a stop sign, which means stop, and there's a green flag, which means go.
So I can, therefore, drag one of these puzzle pieces over here
so that when I click that green flag, the cat will, in fact, do something for me.
Doesn't really matter where I drop it.
So long as it's somewhere in the middle here, I'm going to go ahead and let go.
Now, I want the look of the cat to change.
I want to see a cartoon speech bubble come out for now.
So I'm going to go under looks here.
And there's a bunch of different ways to say things and think things.
I'm going to keep it simple and just drag this one here.
And now notice, when I get close enough to that first puzzle piece,
they're sort of magnetic, and they want to snap together so I can just let go and boom.
Because they're a similar shape, they will lock together automatically.
And notice, too, if I zoom in here, the white oval, which by default says hello,
is actually editable by me.
Because it turns out that some functions can take arguments or, more generally,
inputs that influence their behavior.
So if I kind of click or double click on this,
I can change it to the more canonical hello world or hello David or hello
whatever I want the message to be.
I'm going to go ahead and zoom out.
And now over here at top right, notice that I can very simply click the green flag.
And I'll have written my first program in scratch.
I click the green flag.
It said go.
And now notice it's sort of stuck on that because I never said stop saying go.
But that's where I can click the red stop sign
and sort of get the cat back to where I want it.
So think about for just a moment what it is we just did.
So at the one hand, we have a very obvious puzzle piece that says say
and it said something, but it really is a function.
And that function does take an input represented by the white oval here,
otherwise known as an argument or a parameter.
But what this really is is just an input to the function.
And so we can map even this simple, simple scratch program
onto our model of problem solving before with an addition of what we'll call,
moving forward, a side effect.
A side effect in a computer program is often something
that happens visually on the screen or maybe audibly out of a speaker.
It's something that just kind of happens as a result of you using a function,
like a speech bubble appearing on the screen.
So here, more generally, is what we claimed
represents the solving of a problem.
And let's just consider what the input is.
The input to this problem, say something on the screen,
is this white oval here that I typed in, hello world.
The algorithm, the step-by-step instructions,
are not something really I wrote.
Like our friends at MIT implemented that purple say block.
So someone there knows how to get the cat to say something out
of its comical mouth.
So the algorithm implemented in code is really equivalent to the say function.
So a function is just a piece of functionality implemented in code,
which, in turn, implements an algorithm.
So algorithm is sort of the concept, and the function
is actually the incarnation of it in code.
What's the output?
Well, hopefully, it's this side effect.
Seeing the speech bubble come out of the cat's mouth like this.
All right, so that's one such program.
But it's always going to play and look the same.
What if I actually want to prompt the human for their actual name?
Well, let me go back to the puzzle pieces here.
Let me go ahead and throw this whole thing away.
And if you want to delete blocks, you can either right click
or control click and choose from a menu,
or you can just drag them there and sort of let go, and they'll disappear.
I'm going to go back in and get another event block,
even though I could have reused that same one.
I'm going to go ahead and go under Sensing now.
And if I zoom in over here, you'll see a whole bunch of things.
I can sense distance and colors.
But more pragmatically, I can use this function in blue, ask something,
and then wait for the answer.
And what's different about this puzzle piece
is that it always yes a function.
It too takes an argument, but instead of having an immediate side
effect like displaying something on the screen,
it's essentially inside of the computer going to hand me back the response.
It's going to return a value, so to speak.
And a return value is something that the code can see, but the human can't.
A side effect is something the human sees,
but a return value is something only the computer sees.
It's like the computer is handing me back the user's input.
So how does this work?
Well, notice, and this is a bit strange.
This isn't usually how variables work, but Scratch 2 supports variables.
And that was a word I used quickly at the very start
when we were making the chatbot, a variable like in math, x, y, or z
just stores some value.
But it doesn't have to store a number.
In code, it can store like a human name.
So what's going to happen when I use this puzzle piece
is that once the human types in their name and hits Enter,
MIT, or really Scratch, is going to store the answer, the so-called return
value, in a variable that's designed to be called answer.
But as we'll see, you can make your own variables down the line if you want
and call them anything you want.
But let me go ahead and zoom out.
Let me drag this over here.
I'm going to use the default question.
What's your name?
But I could certainly change the text there.
And let me go under looks again.
Let me go ahead and grab the say block.
And let me go ahead and say, just for consistency, like hello, comma, OK.
And now let me go under maybe sensing.
I want to say, how do I want to say this answer?
Well, notice this.
The shapes are important.
This too is an oval, even though it's not white,
but that's just because it's not editable.
It's going to be handed to me by the ask function.
Let me zoom out and grab a second say block, like this.
And notice it will magnetically clip together.
I don't want to say hello again, so I could delete that.
But now it's still the same shape, even though it's a little smaller.
Let me go back to sensing and notice what can happen here.
When you have values, like words, inside of a so-called variable,
you can use those instead of manual input at your keyboard.
And notice it, too, wants to magnetically slap into place.
It'll grow to fit that variable, because the shape is the same.
And now let's do this.
Let me click the green flag at right.
I'm seeing, quote unquote, what's your name.
I'm getting a text box this time, like on a web page, for instance.
Let me type in my name and watch closely what comes out of the cat's mouth
as soon as I click the check mark or hit Enter.
OK, I got my name right, but let me do it once more.
Let me stop and start.
DAV ID, Enter.
No, it didn't work.
Let me try one other.
Maybe it's my name.
Let's try Kelly, Enter.
What's missing, obviously?
The hello, there's a bug, a mistake in this program.
But is there?
Like, what explains this?
Even if you've never programmed before, intuitively,
what could explain why I'm not seeing hello?
Exactly, it's on two different lines.
So it's doing one after the other.
So it is happening.
It's just you and I, the slowest things in the room,
are just not seeing it in time, because it's happening so darn fast.
Because my computer is so new and so fast, it's happening, but way too quickly.
So how can we solve this?
Well, we can solve this in a few different ways.
And this is where, in Scratch, at least for problems at zero,
wherein you'll have an opportunity to play around with this,
I can scroll around here.
And OK, under Control, I see something like wait.
So I can just kind of slow things down.
And now notice, too, if you hover over the middle of two blocks,
if it's the right shape, it'll just snap into the middle two.
Or you can, just so you know, kind of drag things away to magnetically
separate them.
But this might solve this.
So let me hit Stop and then start.
DAVID Enter.
Hello, David.
All right, that was a little, let's do maybe two seconds to see it again.
Green flag, DAVID Enter.
Hello, David.
It's working better.
It's sort of more correct because I'm seeing the hello and the David,
but kind of stupid to see one and then the other.
Wouldn't it be nice to say it all in one breath, so to speak?
Well, here's where we can maybe compose some ideas.
So let me get rid of this weight in the additional block.
Let's conspire ourselves to just one, say, block.
But let me go down to Operations, where we haven't been before.
And this is interesting.
There's this bigger oval here that says join two things, like apple and banana.
And those are just random placeholder words
that you can override with anything you want.
But they're both ovals and white, which means I can edit them.
So let me go ahead and do this.
Let me drag this on top of the say block.
And this is just going to, therefore, override the hello I put there.
Now I don't want to say apple or banana, but I do want to say hello, comma.
And I then want to say my name.
OK, so now I can go back to Sensing, go back to Answer, drag and drop this here.
That'll snap into place.
And let me zoom in.
Now what I've done is take a function.
And on top of it, I nested another function, the join function,
that takes two arguments, or inputs, and presumably joins them together,
as per its name.
So let's see what this does for us.
Let me click Stop and Start.
I'll type in David, Enter, and it's so close.
Now this is just kind of an aesthetic bug.
What have I done wrong here?
There's no space, so it looks a little wrong.
But that's an easy fix.
I just need to literally go into the hello block after the comma,
hit the space bar, so that now when I stop and start again and type in David,
now I see something that's closer to the grammar we might typically
expect syntactically here.
All right, so let's model this after what we just saw earlier.
We've now introduced a so-called return value.
And this return value is something we can then use in the way we want.
It's not happening immediately like the speech bubble.
It's clearly being passed to me in some way
that I can use to plug in somewhere else like into that join block.
So if we consider the role of these variables playing,
let's consider the picture now as follows.
If the input now to the first function, the ask block,
is what's your name, quote unquote, that's
indeed being fed into the ask block.
And the result this time is not a speech bubble.
It's not some immediate visual side effect.
It is the answer itself stored in a so-called variable
as represented by this blue oval.
Meanwhile, what I want to do is combine that answer with some text
I came up with in advance by kind of stacking these things together.
Now, visually in Scratch, you're stacking them on top.
But it's really that you're passing one into the other into the other.
Because much like math, when you have the parentheses
and you're supposed to do what's inside the parentheses
and then work your way out, same idea here.
You want to join hello and answer together.
And whatever that output is, that then becomes the input to the say block,
which like in math, is outside of the join block itself.
So pictorially, it might now look like this.
There's two inputs to this story.
Hello, comma, space, and the answer variable.
The puzzle piece in question is join.
Its goal in life had better be to give me the full phrase that I want.
Hello, comma, David, let's shift everything over now.
Because that output is about to become the input to the say block, which
itself will now have the so-called side effect.
And so this too is what programming, and in turn, what computer scientist
about is composing with the solutions to smaller problems, solutions
to bigger problems using those component pieces.
And that's what each of these puzzle pieces represents,
is a smaller problem that someone else, or maybe even you, has already solved.
Now we can kind of spice things up here.
If I go back to Scratch's interface, we don't have to use just the puzzle piece
here.
I can do something like this.
Let me go ahead and drag these apart and get rid of the say block.
Down here, just for fun, there's all these extensions
that you can add over the internet to your own Scratch environment.
And if I go to Text to Speech down here, I can, for instance, do a speak block
instead of a say block, colored here in green.
I can now reconnect the join block in here.
And if we could raise the volume just a little bit,
let me stop the old version, start the new version, type in my name,
and hear what Scratch actually sounds like.
Hello, David.
OK, not very cat-like, but we can kind of waste some time on this
by dragging the Set Voice 2 box.
And I can put this anywhere I want above the speak block.
So I'm just going to put it here, even though I've already asked a question.
Maybe kitten sounds appropriate.
Let's try again.
DAVID.
Meow, meow.
OK.
And then let's see, Giant, a little creepier.
Here we go, DAVID.
And lastly, hello, David.
All right, a little ransom like instead.
All right, so that's just some additional puzzle pieces,
but really just the same idea.
But I like that we've introduced some sounds.
So let's do this.
Let me go ahead and throw away a lot of those puzzle pieces,
leave ourselves with just the when green flag clicked,
and play around with some other building blocks
that we've seen already thus far.
Let me go ahead, for instance, under sound,
and let's make the cow actually meow.
So it turns out Scratch, being a cat by default,
comes with some sounds by default, like meowing.
So if we go ahead and click the green flag after programming this program,
let's hear what he sounds like now.
OK, kind of cute.
And if you want it Scratch to meow twice, you can just play the game again.
And a third time.
All right, but that's going to get a little tedious, as cute as it is.
So I can solve that.
Let's just grab three of the puzzle pieces and just drag them together
and let them connect.
And now click the green flag.
All right, it gets less cute quickly.
But maybe we can slow it down so that the cat doesn't sound so hungry maybe.
Let me go under control.
Let's grab one of those wait one second and maybe plop a couple of these
in the middle here.
That might help things.
And now click the green flag.
OK, still a little hungry, but let's see if we change it to two.
And then I change it to two down here in both places.
Let's play it again.
OK, cuter maybe.
But now I'm venturing into badly programmed territory.
This is correct.
If my goal is to get the cat to meow three times, pausing in between,
sorry, three times pausing in between, what is bad about this code?
Even if you've never programmed before, though?
Yeah, in the middle?
Yeah, I literally had to repeat myself three times,
essentially copy-pasting.
And frankly, I could have been really lazy.
And I could right click or control click.
And I could have chosen duplicate.
But generally, when you copy-paste code or when you duplicate puzzle pieces,
probably doing something wrong.
Why?
It's solving the problem correctly, but it's not well-designed.
Even if for only because when I changed the number of seconds,
now I had to change it in two places.
So I had one initially, then I had to change it to two.
And if you just imagine, in your mind's eye,
having not like six puzzle pieces, but 60 or 600 or 6,000,
you're going to screw up eventually.
If it's on you to remember to change something here and here and here
and here, like you're going to mess up.
It's better to keep things simple and ideally
centralized by factoring out common functionality.
And clearly, playing sound and waiting is something
I'm doing at least twice, if not a third time here as well.
So how can we do this better?
Well, remember this thing, loops.
Maybe we can just do something a little more cyclically.
So I tell the computer, do something once,
but I tell it how many times to do that all together.
So notice here, by coincidence, under control,
I have a repeat block, which doesn't say loop,
but that's certainly the right semantics.
Let me go ahead and drag the repeat block in,
and I'll change the 10 to 3 just for consistency here.
I'm going to go back to sound.
I'm going to go ahead and play sound meow until done, just as before.
And just so it's not meowing too fast, under control,
I'm going to grab a wait one second and keep it inside the loop.
And notice that the loop here is sort of hugging these puzzle pieces
by growing to fill however many pieces I actually cram in there.
So now, if I click Play, the effect is going to be the same,
but it's arguably not only correct, but also, well,
because now, if I want to change the weight, change it in one place.
If I want to change the total number of times, change it in one place.
So I've modularized the code and made it better designed in this case.
But now, this is silly because even though I want the cat to meow,
it feels like any program in which I want this cat to meow,
I have to make these same puzzle pieces and connect them together.
Wouldn't it be nice to invent the notion of meowing once
and then actually have a puzzle piece called meow?
So when I want the cat to meow, it will just meow.
Well, I can do that, too.
Let me scroll down to my blocks here in pink.
I'm going to click Make a Block, and I'm
going to literally make a new puzzle piece that MIT didn't think of called meow.
And I'm going to go ahead and click OK.
Now I have, in my code area here, a define block, which literally
means define meow as follows.
So how am I going to do this?
Well, I'm going to propose that meowing just
means to play the sound, meow until done, and then wait one second.
And notice now I have nothing inside my actual program, which begins when
I click the green flag.
But notice at top left, because I made a block called meow,
I now have access to one that I can drag and drop.
So now I can drag meow into this loop.
And per my comment about abstracting the lower level implementation details
away, I'm going to sort of unnecessarily, dramatically,
just move that out of the way.
It still exists.
I didn't delete it.
But now out of sight, out of mind, now, if you agree with me
that meow means for the cat to make a sound,
we've abstracted away what it means mechanically for the cat
to say that sound.
And so we now have our own puzzle piece that I can just now use forever,
because I invented the meow block already.
Now I can do one better than this.
It would be nice if I could just tell the meow block how many times I
want it to meow, because then I don't need to waste time using loops
either myself.
So let me do this.
Let me zoom out.
And let me go back to my defined block.
Let me right click or control click and just edit it.
Or I could delete it and start over, but I'll just edit it.
And specifically, let me say, you know what, let's add an input,
otherwise known as an argument, to this meow block.
And we'll call it maybe n for the number of times I want it to meow.
And just to be super clear, I'm going to add a label, which has no functional
impact, but it just helps me remember what this does.
So I'm going to say meow n time, so that when I see the puzzle piece,
I know what the n actually represents.
If I now click OK, my puzzle piece looks a little different.
At top left, now it has the white oval into which I can type or drag input.
Notice down here in the defined block, I now see that same input called n.
So what I can do now is this.
Let me go under Control, drag the repeat block here.
And I have to do a little switcheroo.
Let me disconnect this, plug it inside of the repeat block, reconnect all of this.
And I don't want 10.
And heck, I don't even want three down here anymore.
I can drag this input because it's the right shape.
And now declare that meowing n times means to repeat the following n times.
Play sound meow until done, wait one second.
And keep doing that n total times.
If I now zoom out and scroll up, notice that my usage of this puzzle piece
has changed, such that I don't actually need the repeat block anymore.
I can disconnect this.
And heck, I can actually right click and control click and delete it.
Just use this under the green flag.
Change this to a three.
And now I have the essence of this meowing program.
The implementation details are out of sight, out of mind.
Once they're correct, I don't need to worry about them again.
And this is exactly how Scratch itself works.
I have no idea how MIT implemented the wait block or the repeat block.
Heck, there's a forever block.
And there's a few others.
But I don't need to know or care because they've
implemented those building blocks that I can then implement myself.
I don't necessarily know how to build a whole chatbot.
But on top of OpenAI's API, this web-based service,
I can implement my own chatbot because they've
done the heavy lift of actually implementing that for me.
Well, let's do just a few more examples here.
Let's bring the cat all the more to life.
Let me throw away the meowing.
Let me open up under when green flag clicked.
How about that forever block that we just glimpsed?
Let me go ahead and now add to the mix what
we called earlier conditionals, which allow us to ask questions
and decide whether or not we should do something.
So under this, let me go ahead and under forever
say if the following is true.
Well, what Boolean expression do I want to ask?
Well, let's implement how about this program.
And we'll figure out if it works.
Under sensing, I'm going to grab this very angled puzzle piece called
touching mouse pointer.
That is the cursor.
And only if that question has a yes answer,
do I want to play the sound meow until done.
So let me zoom in here.
And in English, what is this going to implement, really?
Just describe what this program does less arcanely as the code itself.
Yeah?
Yeah, if you move the mouse over the cat, it will make noise.
So it's kind of like implementing, petting a cat, if you will.
So let me zoom out, click the green flag.
And notice nothing's happening yet.
But notice my puzzle pieces are highlighted in yellow
because it is, in fact, still running because it's doing something forever.
And it's constantly checking if I'm touching the mouse pointer.
And if so, it's like I just pet the cat.
Now it stopped until I move the cursor again.
Now it stopped.
If I leave it there, it's going to keep meowing
because it's going to be stuck in this loop forever.
But it's correct insofar as I'm petting the cat.
Let me do this, though.
Let me make a mistake this time.
Let me forget about the forever and just do this.
And you might think, this is correct.
Let me click the green flag.
Now let me pet the cat.
And nothing's actually working here.
Why, though?
Logically.
Yeah.
Yeah, the program's so darn fast.
It already ran through the sequence.
And at the moment in time when I click the ringer and flag,
no, I was not touching the mouse pointer.
And so it was too late by the time I actually moved the cursor there.
But by using the forever block, which I did correctly the first time,
this ensures that Scratch is constantly checking the answer
to that question.
So if and when I do pet the cat, it will actually detect as much.
All right, about a few final examples before you're
on your way building some of your own first programs with these building blocks.
Let me go ahead and open up a program that I wrote in advance.
In fact, about 20 years ago, whereby, let me pull this up,
whereby we have in this example a program I wrote called Oscar time.
And this was the result of our first assignment in this class,
whereby when MIT was implementing Scratch for the very first time,
we needed to implement our very own Scratch program as well.
I'm going to go ahead and full screen it here.
The goal is to drag as much falling trash as you can to Oscars trash can
before his song ends, for which one volunteer would be handy here.
OK, I saw your hand go up quickly in blue.
Yeah, come on up.
All right, so you're playing for a stress ball here, if we will.
At some point, I'm going to talk over what you're actually playing,
just so that we can point out what it is we're trying to glean from this program.
And I'll stipulate, this probably took me like 8, 12 hours.
And as you'll soon see, the song starts to drive you nuts after a while,
because I was trying to synchronize everything in the game to a childhood
song with which you might be familiar.
Let me go ahead and say hello if you'd like to introduce yourself.
Oh, hello.
So I'm Han.
And I'm a first year student.
I'm pretty excited for this class.
Welcome.
Well, here is Oscar time.
If you want to go ahead and take control of the keyboard, all you'll need to do
is drag and drop trash that falls from the sky into the trash can.
Oh, I love trash.
Anything dirty or dingy or something.
Very nice.
The score is one.
Anything racket or rotten or rusty.
Nice.
Score is two.
Here's I love trash.
All right, good.
Three.
Have you ever seen something trashy?
And let's see what happens.
I have here a sneaker that says I'm wrong.
You'll see a sneaker was perfectly timed.
Thank you very much with the song, after figuring out exactly how many seconds
it had to wait.
Now, Han can drag not only the piece of trash, but the shoe as well.
I love it because it's trash.
And it's around this point in the game where the novelty starts to wear off,
because it's like three more minutes of this game where more and more stuff
starts to fall from the sky.
So as Han, as you continue to play, I'm going to cut over here.
You keep playing.
Let's consider how I implemented this, whereby we'll start at the beginning.
The very first thing I did when implementing Oscar time honestly
was the easy part.
Like, I found a lamppost that looked a little something like this,
and I made the so-called costume for the whole stage.
And that was it.
The game didn't do anything.
You couldn't play anything.
You couldn't green flag.
Nothing happened.
But then I figured out how to turn the scratch cat, otherwise known more
generally, as a sprite, into a trash can instead.
And so the trash can, meanwhile, is clearly animated because I realized
that, oh, I can give sprites, like the cat, different costumes.
So I can make the cat not only look like a trash can,
but if I want its lid to go up, well, that's just another costume.
And if I want to see Oscar popping out, that's just a third costume.
And so I made my own simplistic animation.
And you can kind of see it.
It's very jittery, step by step by step,
by creating the illusion of animation,
by really just having a few different images or costumes on Oscar.
And I hope you appreciate how much effort went involved into timing
each of these pieces of trash with the specific mention of that type
of piece of trash in the music.
OK, 20 years later, still clinging.
So you're doing amazing, by the way.
How do we get the trash to fall in the first place?
Well, at the very beginning of the game,
the trash just started falling from some random location.
What does it mean for trash to fall from the sky?
Big climax here.
Oh.
No, you've got a lot of trash on the ground.
Let's pick up.
Oh.
There we go.
And your final score is a big round of applause, if we could, for hon.
OK.
Thank you.
So just to be clear, now let's decompose this fairly involved program
that took me a lot of hours to make into its component part.
So this is just a sprite.
And I figured out eventually how to change its costume, change its costume,
change its costume to simulate some kind of animation.
And I also realized that, oh, I don't need to just have one sprite,
or one cat, or trash can.
You can create a second sprite, a third sprite, and many more.
So I just told the sprite to go to a random location at y equals 180,
and x equals something.
I think I restricted x to be in this region,
which is why the trash never falls from over here,
just a little bit of math based on that Cartesian plane
that we saw a slide of earlier.
And then I probably had a loop that told the trash to move a pixel,
move a pixel, move a pixel, down, down, down, down,
until it eventually hits the bottom and therefore just stops.
So we can actually see this step by step.
And this is representative of how, even for something
like your first problem said, in CS50 and with Scratch,
specifically, you might build some of the same.
So I'm going to go back into CS50's studio for today, which
is linked on the course's website, which has a few different versions
of this and other programs called Oscar 0 through Oscar 4,
where 0 is the simplest.
And truly, I meant it when I look inside this program to see my code.
Like this was it.
There was no code, because all I did was put the sprite on the screen
and change it from a cat to a trash can.
And I added a costume for the stage, so to speak,
so that the lamp post would be fixated there.
If I then go to the next version of code, version 1, so to speak,
then I had code that did this.
Now notice there's a few things going on here.
At bottom left, you'll see, of course, the trash can.
And then at top right, the trash.
Here are the corresponding sprites down here.
So when Oscar is clicked on here, the trash can,
you see the code I wrote, the puzzle pieces I dragged for Oscar.
And in a moment, when we click on trash,
you'll see the code I wrote, or the puzzle pieces I wrote,
a dragged and dropped for the trash piece specifically.
So what does Oscar do?
Well, I first switch his costume to Oscar 1,
which I assume is this, the closed trash can.
Then forever, Oscar does the following.
If Oscar's touching the mouse pointer, then change the costume to Oscar 2.
Otherwise, that is, if not touching the mouse pointer,
change the costume to Oscar 1.
Well, what's the implication?
Any time I move the cursor over the trash can,
the lid just pops up, which was exactly the animation I wanted to achieve.
Meanwhile, if we do this and click the green flag,
you can see that in action, even for this simple version.
If I move the cursor over Oscar, we have the beginnings of a game,
even though there's no score, there's no music or anything else,
but I've solved one of my problems.
Meanwhile, if I click on the trash piece here,
and then you'll see no code has been written for it yet.
So we move on to Oscar version 2 and see inside it.
And Oscar version 2, when I click on trash, ah,
now there's some juicy stuff happening here.
And in fact, this trash sprite has two programs or scripts associated with it.
And that's fine.
Each of them starts with when green flag clicked,
which means the piece of trash will do two things at once, essentially,
in parallel.
The first thing it will do is it will set drag mode to draggable.
And that's just a scratch thing that lets you actually move the sprites
by clicking on them, making them draggable.
Then it goes to a random x location between 0 and 240.
So yeah, that must be what I did, from the middle all the way to the right.
And I set y always to 180, which is why the trash always
comes from the sky from the very top.
Then I said forever, change your y by negative 1.
And here's where it's useful to know what 180 is, 240 is, and so forth.
Because if I want the trash to go down, so to speak,
that's changing its y by a pixel, by a pixel, by a pixel.
And thankfully, MIT implemented it such that if the trash tries
to go off the screen, it will just stop automatically,
even if it's inside of a forever block,
lest you lose control over the sprites altogether.
But in parallel, what's happening is this.
Also, when the green flag is clicked, the trash piece is doing this too.
Forever, if touching oscar, what's it doing in blue here?
Sort of teleporting away.
Now, to your eye, hopefully, it looks like it's going into the trash can.
But what does that mean to go into the trash can?
Well, I just put it back into the sky as though a new piece of trash is falling.
So even though you saw one piece of trash, two, three, four, and so forth,
it's the same sprite just acting that out again and again.
So here, if I click Play on this program,
you'll see that it starts falling one pixel at a time.
Because it's draggable, I can sort of pull it away and move it over
to the trash can like that.
And as soon as I do, it seems to go in.
But really, it just teleported to a different x location still at y equals 180.
Again, it's not much of a game yet.
There's no score.
There's no music or anything.
But let's go to oscar 3 now.
And in oscar 3, if we scroll over to the trash, even more is happening here.
And so far as I realized, you know what?
There was kind of an inefficiency before.
Previously, I had these two programs, or scripts, synonym, whereby they both went
to the top by going to 0 to 240 for x and then 180 for y.
And if you noticed, I used that here.
And I used that down here in both programs.
Now, that too is kind of stupid because I literally copied and pasted the same code.
So if I ever want to change that design, I have to change it in two places.
And I already proposed that we frown upon that.
So what did I do in this version?
I just created my own block.
And I decided to call my own function go to top.
What does it mean to go to the top, pick a random x between those values,
and fixate on y equals 180 initially.
Now, in both of those programs, which are otherwise identical,
I just say what I mean.
Go to top, go to top.
And if I really wanted to, I could just drag this out of the way
and never think about it again because now that functionality exists.
So correct, but arguably better designed.
I've now factored out commonality so as to use and reuse my code as well.
So let's go up to oscar version 4 now.
And in oscar time version 4, the trash can does a little something more.
Whereby, what have I added to this mix, even though we haven't dragged
this puzzle piece together before?
Yeah, what's new?
Yeah, so it turns out on the left here, there's a variables category,
which goes beyond the answer variable that we just automatically get
from the ask block.
You can create your own variables, x, y, z.
But in computer and programming, it's best to name things,
not silly, simple words like x, y, and z, but full-fledged words
that say what they are, like score.
So I'm setting a score variable to 0.
And then any time the trash is touching oscar
before it teleports away to the top, I change the score by 1.
That is increment the score by 1.
And what Scratch does automatically for me
is it puts a little billboard up here showing me the current score.
So if I now play this game once more, the score is going to start at 0.
But if I drag this trash over here and even let it fall in,
as soon as it touches, the score goes to 1.
And now if I click and drag again, the score is going to.
As soon as it touches oscar, I'm going to go to 2 and so forth.
And you saw in the final Flurs with Hunt playing
that once you add the sound and other pieces of trash, which
are just really other sprites, and I just had wait like a minute,
wait two minutes so that the trumpet would fall at the right time,
I've broken down a fairly involved program into these basic building blocks.
And when you too write your own program, that's exactly how you should approach it.
Even if you have these grand aspirations to do this or that,
start by the simple problems and figure out what bytes can I bite off
in order to make progress, baby steps, if you will, to the final solution.
Well, let's look at one other set of examples
before we have one final volunteer to come up.
And as you'll soon see, it's tradition in CS50
to end the first class with cake.
So in a moment, cake will be served out on the transept.
And please feel free to come up and say hi and ask questions
if you'd like to.
Let me go ahead and open up, though, a series of building blocks here,
via which we can make so-called Ivy's Hardest Game, which is one implemented
by one of your predecessors, a former classmates from CS50.
So here we have a whole bunch of puzzle pieces written by your classmates.
But let me go ahead and zoom in on this screen.
You'll see that this Harvard Crest is my sprite, so it's not a trash can.
It's a Harvard Crest.
And it exists in a very simple two-dimensional world
with two walls next to it.
If I click on the green flag, notice that with my hands here, I can go up,
I can go down, I can go left, and I can go right.
But if I try going too far right, I get stuck on the wall.
If I go too far left, I get stuck on the wall.
Well, it's sort of the beginning of any animation or game.
But how do I do this?
Well, let me go up here and propose that the first thing the Harvard sprite is
doing is it's going to the middle, 0 comma 0.
And it's then forever listening for the keyboard and feeling for walls.
Now, those are functions I implemented myself
to kind of describe what I wanted the program to do.
And let's do the shorter one first.
What does it mean to feel for the walls?
Just to ask the question, if you're touching the left wall, change your x by 1.
If you're touching the right wall, change your x by negative 1.
Why have I defined touching walls in this weirdly mathematical way?
Yeah?
Sure, yeah.
And you just do a camera wrap to make it easy to get it otherwise if you're
like net attack, it's not easy.
Exactly.
Because if I've gone so far right that I'm touching the right wall,
well, I'm already kind of on top of the wall a little bit.
So I effectively want the sprite to bounce off of it.
And the easiest way to do that is just to say, back up one pixel,
as though you can't go any further, and same for the left wall.
Meanwhile, let me scroll over to the second script or program that's
running in parallel.
It's a little longer, but it's not more complicated.
What does it mean to listen for keyboard?
Well, just check.
If the key up arrow is pressed, change y by 1.
Ergo, go up.
Else if the key down arrow is pressed, then change y by negative 1.
Key right arrow is pressed, change x by 1, and so forth.
So again, this is where the math and the numbers are useful,
because it gives you a world in which to live, up down left right,
deconstructed into some simple arithmetic values.
All right, so the net result is that we have a crest living in this world.
Well, let's add a bit of competition here.
And then the second version of this game, let me go ahead and full screen it again.
Click Play.
And now we'll see sort of an enemy bouncing back and forth autonomously.
So there's no one playing except me.
I'm controlling Harvard.
Yale is bouncing on its own, and nothing bad's
going to happen if it hits me, but it does seem to be autonomous.
So how is this working?
Well, if it's doing this forever, there's probably a forever loop involved.
So let's see inside here.
Let's click not on Harvard, but on the Yale sprite.
And sure enough, if we focus on this for a moment,
we'll see that the first thing Yale does is go to 0, 0.
It points in direction 90 degrees, which just
gives you a sense of whether you're facing left or right or wherever.
And then it forever does the following.
If it's touching the left wall or touching the right wall,
I was a little clever this time, if I may.
I just kind of turn around 180 degrees, which effectively bounces me back
in the opposite direction.
Otherwise, I go ahead and, no matter what, just move one step.
And this is why Yale is always moving back and forth.
So a quick question.
If I wanted to speed up Yale and make this beginning of a game harder,
what would I do?
Yeah?
You think you'd like to move a bigger number?
Yeah, so let's have it move like 10 steps at a time.
This looks like a much harder game, if you will, like level 10 now,
because it's just moving so much faster.
All right, well, let's try a third version of this that adds another ingredient.
Let me full screen this and click Play.
And now you'll see the even smarter MIT homing in on me
by following my actual movements.
So this is sort of like boss level material now.
And it's just going to follow me.
So how is this working?
Well, it's kind of a common game paradigm.
But what does this mean?
Well, let's see inside here.
Let's click on MIT Sprite.
It's pretty darn easy.
Go to some random position, just to make it a little interesting,
let MIT always start in the center.
And then forever, point towards the Harvard logo outline,
which is the name the former student gave to the costume
that the sprite is wearing that looks like a Harvard crest,
and then move one step.
So a corollary of the previous question, how
do we make the game harder and MIT even faster?
Well, we can change this to be like 10 steps.
And now you'll see MIT is a little twitchy,
because this is kind of a visual bug.
Let me make it full screen.
Why is this visual glitch happening?
It's literally doing what I told it to do.
It just looks stupid.
Yeah.
Say again?
Yeah, it's moving so fast that it's sort of going 10 pixels this way,
but then it kind of overshot me.
So then it's doubling back to follow me again, and it's doubling back this way.
And because these are such big footsteps, if you will,
it just has this visual effect of twitching back and forth.
So I might have to throttle that back a bit and make it 5, or 2, or 3,
instead of 10, because that's clearly not desirable gaming behavior here.
All right.
Well, let's go ahead and do this.
Let's put them all together, just as your former classmate did
when submitting this actual homework.
The game will conclude, hopefully, in an amazing climax
where you've won the game.
So we need someone, ideally, with really good hand-to-eye coordination
to play this final game here.
Yeah?
Your hand went up first, I think?
OK, come on up.
Big round of applause, because there's a lot of pressure to end.
All right.
So if you win the game, cake will be served.
If you don't win the game, there will be no cake.
OK?
OK.
But introduce yourself in the meantime.
Hi, I'm Jenny Pan, freshman at Hollis, and I'm actually a CS major.
Nice.
Or concentration.
Nice to meet you.
I'll head to the keyboard here.
This now is the combination of all of those building blocks,
and even more, AKA IB's hardest game, you will be in control, just like me.
And the goal is to make it to the exit, which is this gentleman on the right here.
And you'll see there's multiple levels, where each level gets a little harder.
All right.
Here we go.
You can't touch this.
You can't touch this.
Very good.
You can't touch this.
Nicely done.
You can't touch this.
So the loop has been added for Yale.
You can't touch this.
So the loop has been added for Yale.
Good.
Two Yale's now.
All right.
Three Yale's now.
Nice.
Here comes MIT.
Very good.
Yeah.
Two MIT's.
Nice.
Yes.
Yes.
Yes.
Now, Princeton.
Another Princeton.
Second to last level.
Yes.
Last level.
So close.
Keep going.
Yes.
Congratulations.
All right.
This is CS15.
Cake is now served.
Thank you.
